Name: Single Ring Crankset w/ Narrow-Wide Chainring
Brand: Velo Orange
SKU: CR-0034-165
Price: 165.0 USD
Availability: OutOfStock

Single Ring Crankset w/ Narrow-Wide Chainring

Crankarm Length

165 mm

170 mm

175 mm

Price

Free USA shipping on order subtotals over $150

Secure payments

Quantity

[{"id":50649717063,"title":"165 mm","option1":"165 mm","option2":null,"option3":null,"sku":"CR-0034-165","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Single Ring Crankset w\/ Narrow-Wide Chainring - 165 mm","public_title":"165 mm","options":["165 mm"],"price":16500,"weight":0,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"815667013955","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":50649716999,"title":"170 mm","option1":"170 mm","option2":null,"option3":null,"sku":"CR-0034-170","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Single Ring Crankset w\/ Narrow-Wide Chainring - 170 mm","public_title":"170 mm","options":["170 mm"],"price":16500,"weight":0,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"815667013962","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":41063522566319,"title":"175 mm","option1":"175 mm","option2":null,"option3":null,"sku":"CR-0034-175","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"Single Ring Crankset w\/ Narrow-Wide Chainring - 175 mm","public_title":"175 mm","options":["175 mm"],"price":16500,"weight":0,"compare_at_price":null,"inventory_quantity":-1,"inventory_management":"shopify","inventory_policy":"deny","barcode":"815667016567","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Here is a durable and stylish single ring crankset ready for a 1x, singlespeed, fixed gear, or even an internal rear hub!

Cold forged and machined from 7075 aluminum alloy this chainset is strong and light. The 42 tooth chainring features a narrow-wide profile for excellent chain retention for all drivetrain styles.

All stainless hardware with allen head nuts/bolts. Includes aluminum machined dust caps and BB bolts. Dust caps function as self extracting crank hardware.

Specs:

Teeth: 42, narrow-wide
BCD: 110
Q Factor: 134mm
Chainline: 42mm
Chainring width: 3/32"
Taper: JIS square taper
BB Size: 110mm BB on many road and track bikes
Pedal Threading: 9/16"
Weight: 592 gr including dust caps and bolts

Free Shipping for Retail customers with subtotals over $150: Velo Orange offers free shipping to the lower 48 States for retail orders with a subtotal of at least $150. Use the coupon code 150SHIP when you check out to get the deal.

Free Shipping for Wholesale customers with subtotals over $400: Velo Orange offers free shipping for wholesale orders to the lower 48 States with a subtotal of at least $400. No coupon code required for this deal.

Oversize international shipping: Large products including (but not limited to) frames, fork, fenders, handlebars, racks, and rims may incur oversize shipping charges. We will notify you of additional charges.

For additional info, please visit our FAQ page or contact us.

Narrow Wide Chaining

Nice 👍🏽

Quality Crankset

Its like a jewel for your bike.

Add required chain stay width to the product info

Building my own bike, I read numerous articles on BB spindle and they all basically said to go with what the crank manufacturer recommends, so I did. Well the Q factor is so narrow that using the recommended BB spindle (110) with these 175 mm cranks they would not clear the chain stay. I had to buy a wider 118 spindle BB and it barely clears the chain stay (width at end of a 175mm crank installed on IRD 110 spindle BB was 111 mm on my New Albion Privateer frame). They should post minimum chain stay widths for each crank length for their "recommended" 110 spindle length. Otherwise you will have to use trial and error, possibly buying multiple bottom brackets that cannot be returned after being installed. Then you have chain line to consider. Aside from that the cranks work, look good, and they have nice bolt caps. I'm running it on a 118 spindle shimano BB UN-300 with an 8 speed chain on a 20 tooth Shimano Nexus internally geared hub, good drivetrain setup. Most importantly, there were no other decent cranks at this price in-stock so there's that to consider.

Simple Setup

The 1x is a great simple setup. Using this with Microshift Advent X. Works really well.

Great addition to build!

Just put this on a 1992 Bridgestone XO-3 frame I picked up and am doing up as a friction shifting 1x8. Looks beautiful, works great.
